The RCV-302 remote controller is for Windows Media Center Technologies in Windows Vista Home Premium and Windows Vista Ultimate.  It lets you access and manage your Media Center PC and other peripheral devices.  All the buttons and functions necessary for Microsoft certification included, including official Green Button.

Features
Microsoft Windows Vista certification and Vista Green Button support
Use standard Microsoft drivers, no software to install
Include all of the buttons and functions necessary for Microsoft certification, including official Green Button, 5-way Joystick, 3 dedicated Activity buttons, Numeric keypad
Small IR USB dongle receiver
It allows to wake up the PC system from S1 or S3
Infrared Rays Frequency:  38KHz
Infrared Rays transmission distance:  7 ~ 10 meters
Support on indication LED for the system level interaction


Specifications
49 buttons remote that includes all of the buttons and functions necessary for Microsoft certification, including official Green Button
Small USB dongle style receiver
Protocol: RC6 IR Protocol
Infrared Rays Frequency:  38KHz
Dimension:
  Remote Control: 180 mm x 54 mm X 20 mm
  IR USB Receiver:  43 mm x 18.3 mm x 15.5 mm
Weight:
  Remote Control:
  IR USB Receiver:


System Requirements
Intel Pentium IV or AMD Athlon and above
512 MB RAMor above(1GB recommaended)
Window Vista Home Premium or Ultimate
PC plateform with USB port
Graphic card capable of DirectX9


Product Contents
MS Vista Remote Control (RCV-302) x 1
IR USB Receiver  x 1
AAA Type Battery x 2
User's Manual x 1
